PowerPact B-frame circuit breaker, offers proven performance, flexibility, and reliability. This PowerPact Molded Case Circuit Breaker feature new innovations such as the patented EverLink⢠connections. PowerPact B-frame circuit breakers provides economical thermal magnetic circuit protection with a breaking capacity of 25kA at 220 / 240 VAC50/60 Hz. PowerPact B-frame circuit breakers come in 1 to 4-pole unit mount construction also 1 to 3-pole I-Line construction. This Powerpact B, 60 A, 2P, circuit breaker has a breaking capacity of 65kA@480VAC@50/60 Hz per UL 489 standards. This circuit breaker has aThermal-magnetic trip unit technology with a mechanical service life of 20000 cycles and an electrical service life of 10000 cycles@440V. This clip-on breaker has a presence of auxiliary contacts green signaling function. The I-Line lug can accept an AWG gauge AWG 6/AWG 2/0, aluminium/copper. This breakers complies to UL, IEC, CCC, EAC, CSA, NOM standards. Powerpact B-Frame breakers have an operating altitude test condition of 2000 m without derating and a 5000 m with derating. Dimensions for this product are 137 mm (H),54 mm (W),80 mm (D) and a weight of 0,769 kg This breaker has a continuous current rating of 80%.
PowerPact B Circuit Breaker, 60A, 2P, 600Y/347V AC, 25kA at 600Y/347 UL EverLink
PowerPact B Circuit Breaker, 60A, 2P, 600Y/347V AC, 25kA at 600Y/347 UL EverLink
SKU: 16942017
Category: Power Distribution
Reviews (0)
Be the first to review “PowerPact B Circuit Breaker, 60A, 2P, 600Y/347V AC, 25kA at 600Y/347 UL EverLink” Cancel reply
