Square D EZ Meter-Pak main devices are available as main circuit breakers, main fusible switches, or main lug terminal boxes. EZM main circuit breaker provides circuit protection and a main disconnect point suitable for service equipment. This main circuit breaker unit supplies one phase in, one phase out with a three wire configuration. It is rated for 120/240VAC and 300A. It is suitable for underground and overhead service feed. The compartment has three horizontal 400A rated busbars. The busbars come with Visi-Tite joint nuts for connections, eliminating the need for torque readings. It is supplied with 300A two-pole circuit breakers. It is compliant with UL standards and the steel enclosure has a rating of NEMA 3R.
Main circuit breaker unit, EZ Meter-Pak, 300A, 120/240VAC, 1 phase, 3 wire, 400A busbar, UG and OH, 300A CB
Main circuit breaker unit, EZ Meter-Pak, 300A, 120/240VAC, 1 phase, 3 wire, 400A busbar, UG and OH, 300A CB
SKU: 16936601
Category: Meters & Accessories
Reviews (0)
Be the first to review “Main circuit breaker unit, EZ Meter-Pak, 300A, 120/240VAC, 1 phase, 3 wire, 400A busbar, UG and OH, 300A CB” Cancel reply
