Square D individual meter sockets have provisions to feed a downstream main lug load center, main breaker load center, or an individually enclosed service disconnect. Units can have a combination of releases, horn, or no bypasses to handle any meter socket situation. Units supplied with hub opening in top end wall require the use of a bolt-on hub or closing plate. With 200 A, 600 V, 1 phase, 4 jaws ringless socket your product can provide 10 kA RMS short circuit rating. These units are supplied with a bonded neutral to the NEMA 3R enclosure. Meter sockets are UL Listed.
Meter socket, 100 A, 600 V, 1 PH, ringless, 4 jaws w/o release, horn, NEMA 3R, steel
Meter socket, 100 A, 600 V, 1 PH, ringless, 4 jaws w/o release, horn, NEMA 3R, steel
