This product is part of the XZ range, an offer of machine cabling accessories. This jumper cable is an accessory of photoelectric sensors for connecting separate muting sensors. The length of this cable is 2m and diameter is 5.2mm. It is furnished with 4-pin M12 straight male connector on the one end and 4-pin M12 elbowed female connector on the other end with screw-on fixing. It is a connection cable with a rated operating voltage of 250V AC and 300V DC and a rated current of 4A. It is an IP65, IP67 and IP69K rated product. This jumper cable has a PUR insulation. It weighs 0.095kg. It is ideal for material handling, packaging, labelling, assembly, lift, escalators or food and beverage industries. This product is certified by CULus. Ex Osiris, OsiSense XU is for non-contact sensing up to a hundred meters of objects of any shape and any type.
jumper cable – male M12 – 4-pin straight – female M12 – 4-pin elbowed – cable 2m
jumper cable – male M12 – 4-pin straight – female M12 – 4-pin elbowed – cable 2m
