This kit include current transformer with a line rated current of 100 A and a secondary voltage rating of 0.333 V. This split-core do have a 16 mm x 20 mm opening. Accuracy class 1 when used with BCPMSC. Electrically connected to the board with the help of a 6.1m flying lead. This kit include 6 split-core current transducers.
BCPM 100A split-core CTs – set of 6 – 6m lead lengths
BCPM 100A split-core CTs – set of 6 – 6m lead lengths
