Absolute encoder Ø 58 multi turn – hollow shaft 15 mm – 25-bit binary – PROFIBUS

This product is part of the XCC range, an offer of opto-electronic rotary encoders. This multiturn absolute encoder has a diameter 15mm hollow shaft and a 25-bit binary, PROFIBUS communication protocol output. The maximum revolution speed is 6000RPM, the resolution is 4096 turns/8192 points and shaft tolerance is F7. It is furnished with 3 cable glands PG9 radial external supply for electrical connection. It is an IP64 rated product. It is a multiturn absolute encoder with a current consumption of 0mA to 100mA (no-load), a rated voltage of 24V DC and an output frequency of 800kHz. It has 2 LEDs to facilitate monitoring and diagnostics. The enclosure is made of aluminium, the base of aluminium and the shaft of stainless steel. Its dimension is 58mm (Diameter) and weighs 0.57kg. It is suitable for use in many industries including packaging, cutting machines, robots, cranes, materials handling, automatic dispensers, printing shops, continuous processes and conveyor systems, etc. This product is certified by CE and DIN VDE 0160. It meets Schneider Electric interoperability standards. A range of innovative rotary encoders opened to field BUS and greatly simplify resolution parameter-setting. The PROFIBUS-DP bus interface integrated in the encoder is based on RS 485 transmission and enables speeds of up to 12 Mbps. Ex Osicoder optical rotary encoders for all counting, position and speed information requirements.
