HomeLow Voltage Transformers Unit substation, Mini Power-Zone, bolt on, 30kVA, 3 phase, 480V primary, 208Y/120V secondary, 18kA, CC, stainless steel
Previous product
primary_image
Circuit breaker, PowerPacT P, 1200A, 3 pole, 600VAC, 25kA, I-Line, Micrologic 5.0A, 80%
Back to products
Next product
primary_image
servo motor SH3 100 5,8Nm,nokey,single,brake,str.conn,IP54/IP65,6k RPM

Unit substation, Mini Power-Zone, bolt on, 30kVA, 3 phase, 480V primary, 208Y/120V secondary, 18kA, CC, stainless steel

Unit substation, Mini Power-Zone, bolt on, 30kVA, 3 phase, 480V primary, 208Y/120V secondary, 18kA, CC, stainless steel

SKU: 172540447 Category: Low Voltage Transformers
Share
Facebook Twitter Pinterest linkedin Telegram
  • Description
  • Reviews (0)
Description

Square D™ brand Mini Power-Zone™ unit substation from Schneider Electric provides the answer to requirements for a portable, compact power supply for small loads. The Mini Power-Zone unit substation uses a separate transformer and panel section. This allows the panel section to be removed and wired first if desired. These transformers can be replaced without disturbing the panel section and associated wiring. The new transformer simply slides into the top of the panel section and primary and secondary leads are reconnected to the main circuit breakers. The panel section uses Square D™ brand QO™ style circuit breakers. Use Qwik-Gard™ circuit breakers for required ground fault protection. This Mini Power-Zone Sealed Transformer is a 1 phase, with a primary voltage of 480V and a secondary voltage of 208Y/120V with 2 tap offs @5 % FCBN taps. This transformer has a box number CC and a insulation temperature rating of 185 °C. These transformers are installed on the interior of the load center that has 24 spaces. With a rated power of 30kVA, it has a short circuit current of 18kA. This transformer has a temperature rise of 115°C and is epoxy-resin encapsulated. The enclosure material is stainless steel 316 and is rated at NEMA 3R. This transformer complies to UL listed standards. This product comes with an 18 month warranrty.
