HomePressure Switches Pressure switch 9012G, adjustable scale, 2 thresholds, 3.0 to 150 PSIG
Previous product
primary_image
Head for key selector switch, Harmony XB5, XB4, Ø22 mm 3 position spring return 421E
Back to products
Next product
Placeholder
TRANSFORMER CURRENT 400:5 1-9/16 I

Pressure switch 9012G, adjustable scale, 2 thresholds, 3.0 to 150 PSIG

Pressure switch 9012G, adjustable scale, 2 thresholds, 3.0 to 150 PSIG

SKU: 14874607 Category: Pressure Switches
Share
Facebook Twitter Pinterest linkedin Telegram
  • Description
  • Reviews (0)
Description

This product is part of the Nema Pressure Switches range, an offer of electromechanical pressure switches. This electromechanical pressure switch has normally closed – normally opened, SPDT (single pole double throw), form C, snap action contacts and a range on decreasing pressure of 3psi to 150psi. The pressure switch with an approximate adjustable differential at mid range of 4.2psi to 22psi and a maximum pressure of 475psi. It is furnished with screw clamp terminals for electrical connection and 0.25inch 18 NPTF for fluid connection. This switch has a diaphragm actuator which can be operated from any position, adjustable differential scale for internal settings and regulation of 2 thresholds. Offers mechanical durability of about 5 million operating cycles. The enclosure is made of thermoplastic. It is available in size of 2.21inch (W) x 2.75inch (D) x 6.94inch (H) and weighs 2lb. It is suitable for pressure controlling or monitoring of water pumps, compressors, agricultural/irrigation water systems, moulding presses, injection moulders, grinding machines, machining centres, complex and special machines. It is a NEMA 1 rated product. This product is certified by CE, CSA and UL. Meets UL 508 standards. Single stage pressure switch is control circuit rated device used in pneumatic or hydraulic systems on a wide variety of machine and process applications to protect the equipment and control or monitor the system pressure.
