Square D EZ Meter-Pak branch meter compartments provide a compact footprint for multi unit construction applications. This branch unit supplies three phases in, one phase out with a four wire configuration. It is rated for 208Y/120VAC and 125A. The meter socket compartment has six ringed, five jaw meter sockets. The compartment has four horizontal 1200A rated busbars with copper vertical connectors. The busbars come with Visi-Tite joint nuts for connections, eliminating the need for torque readings. It is compatible with 40A to 125A two-pole plug-on QO circuit breakers. It is compliant with UL standards and the steel enclosure has a rating of NEMA 3R.
Branch unit, EZ Meter-Pak, 125A, 6 sockets, 208Y/120VAC, no bypass, ringed, 1200A copper busbar
Branch unit, EZ Meter-Pak, 125A, 6 sockets, 208Y/120VAC, no bypass, ringed, 1200A copper busbar
SKU: 9030280
Category: Meters & Accessories
Reviews (0)
Be the first to review “Branch unit, EZ Meter-Pak, 125A, 6 sockets, 208Y/120VAC, no bypass, ringed, 1200A copper busbar” Cancel reply
